RG 59/U-6 Cu/Cu

PDF Catalogue
  • It is used as a distribution cable for indoor CATV, CCTV systems and as a connection cable for satellite systems where lower attenuation is required.
Conductor0,80mm Ø Electrolytic Copper
Insulation3,70mm Ø Physical Foam PE
1.ScreenCu-Pes Tape (100% Coverage)
2.ScreenElectrolytic Copper Braid
Sheath5,80mm Ø PVC Compound White
Total Weight39kg/km
Standard Length100/500/1000/2000m



INSULATION
RESISTANCE		MUTUAL
CAPACITANCE		VELOCITY OF
PROPAGATION		OPERATING
VOLTAGE		TEST
VOLTAGE		BENDING
RADIUS		TEMPERATURE
RANGE		IMPEDANCEFLAME RETARDANT
TEST
>2000MΩxkm53±2 pF/mt82 %1,1 kV2,5 kV15x Cable Ø– 40ºC+70ºC75±3 ΩIEC 60332-1-2
DIN EN 60332-1-2
EN 60332-1-2
