RG 59/U-4 Cu/Al HFFR
- It is used as a distribution cable for indoor CATV, CCTV systems and as a connection cable for satellite systems where lower attenuation is required.
- These cables which have flame retardant characteristics by their design are used in places where people are densely populated (such as shopping centers, hotels etc.) and in places where no smoke and corrosive gases required which emitted by fire that threats human health.
| Conductor | 0,80mm Ø Electrolytic Copper |
| Insulation | 3,70mm Ø Physical Foam PE |
| 1.Screen | Al-Pes Tape (100% Coverage) |
| 2.Screen | Aluminium Braid |
| Sheath | 5,80mm Ø HFFR Compound Black or Grey |
| Total Weight | 35kg/km |
| Standard Length | 100/500/1000/2000m |
| INSULATION RESISTANCE | MUTUAL CAPACITANCE | VELOCITY OF PROPAGATION | OPERATING VOLTAGE | TEST VOLTAGE | BENDING RADIUS | TEMPERATURE RANGE | IMPEDANCE |
| >2000MΩxkm | 53±2 pF/mt | 82 % | 1,1 kV | 2,5 kV | 15x Cable Ø | -40ºC+70ºC | 75±3 Ω |
| FLAME RETARDANT TEST | SMOKE DENSITY TEST | TEST ON CORROSIVENESS OF COMBUSTION GASES | HALOGEN FREE TEST | FLAME PROPOGATION TEST |
| IEC 60332-1-2 | IEC 61034-2 | IEC 60754-2 | IEC 60754-1 | IEC 60332-3-25 |
